Description
|
Structural Details:
|
|
| Tunnel Length |
3 Meters (10 Feet)
|
| Tunnel Height |
2.4 Meters (8 Feet)
|
| Tunnel Width |
1.2 Meters (4 feet)
|
| Easy Assembly | YES |
| Channel Size |
1 inch Stainless Steel Tube
|
| Base Platform | Yes |
| Collection Tank | Yes |
| Coating | Polished |
| Storage Tank | 225 Liters |
| Side and Top Covering |
Acralyic 4 mm thickness
|
| Tank and motor Location |
On the ground for easy refill
|
| Rubber bottom Bush | Yes |
|
Pump Details:
|
|
| Brand Name | Tech Pumps |
| Model Name | Greenly-001 |
| Discharge Capacity |
72 LPH / 1.2 LPM
|
| Pump Type |
SINGLE PHASE. SUCTION PUMP
STAINLESS STEEL SHAFT SUCTION LIFT = UP TO 7 METERS LIQUID TEMP = UP TO 50 C MOTOR = 2 POLE INDUCTION MOTOR 50 HZ, 2900 RPM SINGLE PHASE 230V +5% TO -15% DOUBLE SEALED BALL BEARINGS CLASS F/B CAST IRON CASING AND BRACKET WITH BRASS IMPELLER WITH DRY RUN AND FLOAT |
| Warranty | 1 Year |
|
Mist Nozzle:
|
|
| Brand Name |
Synergy Spray Systems
|
| Model Number |
TRUEMIST-0003
|
| Orifice Diameter | 0.3 mm |
| Output per nozzle | .15 LPM |
| Total Number of Nozzles | 8 Pieces |
|
Other Details:
|
|
| Tube Details | HDPE tube |
| Stainers |
Double Stainers
|
| MOQ for Branding | 5 set |
|
Chemicals (not included in the package):
|
|
| Brand Name | Greenly L10 |
| Basic Price. Ex-works | 89500 |
| GST@ 18% | 16110 |
| Total Cost | 105610 |
